BP-0300-CR-XP15: Double Pantry Faucet, Single Hole, Ceramas, 133XP-F15 Swivel Gooseneck, Lever Handles

Name: Double Pantry Faucet, Single Hole, Ceramas, 133XP-F15 Swivel Gooseneck, Lever Handles
Brand: T&S Brass
Price: 386.00 USD
Availability: InStock

share this page Where to Buy

List Price

$386.00

Single hole deck mount mixing faucet with polished chrome plated brass body, 5 11/16" swivel/rigid gooseneck with plain end outlet and 1.5 GPM flow control device, ceramic cartridges with check valves, lever handles withvandal resistant screws and 19" flexible stainless steel supply hoses with 3/8" compression connections. Certified to ASME A112.18.1 / CSA B125.1,NSF 61-Section 9 and NSF 372. Meets ADA ANSI/ICC A117.1 requirements.

Nozzle Flow: Nozzle Flow: 1.5 GPM (5.68 L/min)
Pressure Max: Pressure Max: 125 psi (8.62 bar)
Pressure Min: Pressure Min: 20 psi (1.38 bar)
Temperature Max: Temperature Max: 140 F (60℃)
Temperature Min: Temperature Min: 40 F (4.44℃)

Body: Single Hole
Body Mount: Deck
Cartridge-Spindle: Ceramic
Feature: Check Valve
Feature: Vandal Resistant Handle Screws
Handle: Lever
Material: Brass Construction
Nozzle: 6 in (152.4 mm)
Nozzle: Gooseneck
Nozzle: Swivel
Nozzle Flow: 1.5 GPM (5.68 L/min)
Nozzle Outlet Type: Flow Regulator
Nozzle Outlet Type: Plain End
Pressure Max: Pressure Max: 125 psi (8.62 bar)
Pressure Min: Pressure Min: 20 psi (1.38 bar)
Temperature Max: Temperature Max: 140 F (60℃)
Temperature Min: Temperature Min: 40 F (4.44℃)

1.5 GPM flow control device (pre-installed in gooseneck swivel)
19" flexible stainless steel supply hoses w/ 3/8" compression connections
5 11/16" swivel/rigid gooseneck w/ plain end outlet
Lever handles w/ color coded indexes
Lock washer provided for rigid application
Material: Polished chrome plated brass body & tubular spout and chrome plated metal handles
Quarter-turn Cerama cartridges with check valves to prevent cross flow of water
Single hole deck mount mixing faucet w/ polished chrome plated brass body
Vandal resistant screws

ASME A112.18.1 / CSA B125.1
Buy American Act (BAA)
EPA WaterSense
Low Lead Content (0.25% Max)
NSF/ANSI 372 (Lead Content)
NSF/ANSI/CAN 61 Q≤1

Box Dimensions: 3.75 x 10.25 x 15.44
Weight: 5.81 lbs (2.64 kg)
UPC: 671262814195

ANSI A117.1 (ADA)

ANSI A117.1 (ADA)

ANSI A117.1 (ADA)
California Prop #65 Warning

California Prop #65 Warning

WARNING

California Proposition 65

WARNING: This product can expose you to chemicals including Lead, Chromium (hexavalent compounds) and Phthalates (DEHP) which are known to the State of California to cause cancer and birth defects or other reproductive harm.

For more information, please go to www.P65Warnings.ca.gov.
Country Of Origin: China

Related Literature

downloads

- Spec Drawings/Parts Explosion
Installation Instructions
- Base Assembly Faucet
- Submittal
Warranty: One Year (Limited)

Replacement Parts Parts Explosion

133XP-F15
Plain-End Swivel Gooseneck, 5-11/16" Spread, 10-5/16" Height, 6-5/16" Clearance, 1.5 GPM click for details
009538-45
Split Swivel Washer (Delrin) Identical to 001028-45 click for details
011429-45
Swivel Sleeves (Two-Pack) click for details
001074-45
Swivel Nozzle O-Ring #2-114 (Nitrile) click for details
FD15
Flow Control Disc, 1.5 GPM, Green Insert click for details
014200-45
EasyInstall S'Steel Lock Washer (Swivel/Rigid) click for details
012395-25NS
Cerama Cartridge w/ New Style Bonnet, Check-Valve, LTC (Cold) click for details
VRS-2
Kit, VR Wrist Handle Screws & Spanner Bit click for details
018506-19NS
Press-In Index, Medium-Blue, T&S Logo click for details
002290-45
Brass Washer: 1-31/32" OD, 1-3/16 ID, 3/32" Thick click for details
000965-45
B-0113 Shank Lock Nut click for details
019969-45
19" Flex SS Supply Hoses, 3/8" Compression Female Swivel Inlet, M10x1.0 Connection (Qty2) click for details
012394-25NS
Cerama Cartridge w/ New Style Bonnet, Check-Valve, RTC (Hot) click for details
001638-45NS
Lever Handle, Blank (New Style) click for details
001193-19NS
Press-In Index, Red, T&S Logo click for details
